Model | WA-775 | WA-777 |
Platform | Pentium 3 | Pentium 4 |
Processor | Intel Ultra Low Voltage Celeron 650MHz (Embedded) | Intel Celeron 2GHz (socket 478) |
Memory | 256MB standard, maximum 512MB (1 x 144-pin SO-DIMM)) | 256MB standard, maximum 1GB (1 x 184-pin DDR) |
Touch LCD Display | ||
Size / Resolution | 15" TFT LCD / 1024 x 768 | 15" TFT LCD / 1024 x 768 |
Brightness | 250 ~ 350 cd/㎡ | 250 ~ 350 cd/㎡ |
Touch Screen | ELO 5-wire Resistive/Fujitsu 4-wire Resistive | |
I/O Connectivity | ||
Serial Port | ● 3 x External: COM1 & COM2 (D-Sub) | ● 2 x External: COM1 & COM2 (D-Sub) |
COM4 (RJ45) for Barcode Scanner | ● 3 x Internal: COM3 for Primary Touchscreen | |
● 1 x Internal: COM3 for Primary Touchscreen | COM4 for Barcode Scanner | |
COM5 (user available) | ||
Parallel Port | 1 x Parallel | |
Standard USB Port | 4 x USB 2.0 (2 x internal, 2 x external) 1 x USB 1.1 (external) | 4 x 2.0 USB (2 x external, 2 x internal) |
Mouse Port | N/A | 1 x PS/2 Mouse |
Keyboard Port | 1 x PS/2 keyboard | |
LAN Port | 1 x RJ45 10/100 Base-T | |
VGA Port | 1 x VGA | |
IDE Hard Disk Drive | Built-in 3.5" 40GB (standard) | |
Compact Flash | CF slot available | |
Speaker | Integrated 12W stereo speakers | |
Power Supply | 65W External Power Adapter | 250W External Power Adapter |
Construction | Aluminum Die-casting Housing | |
Housing Color | Black | |
O/S Supported | Win2000, XP (Pro, Embedded), WEPOS | |
Dimensions ( W x H x D) | 370 x 380 x 100 mm | 370 x 380 x 180 mm |
Weight | 6 Kgs | 7.5 Kgs |
EMI/Safety | CE, FCC, UL, RoHS | |
Operating Temperature | 0℃ ~ 35℃ | |
Optional Peripherals | ||
Magnetic Stripe Card Reader | Integrated MCR Single/Dual/Triple Track | |
Barcode Scanner | Integrated Laser Barcode Sacnner (Metrologic IS3480) | |
Wireless LAN | Integrated 802.11b/g Wireless LAN Module (USB interface) |
