MECHANICAL | Available Size Input Method Glass Thickness |
10.4” to 19” Finger 3mm (for sensor size above 10.4”) |
ELECTRICAL | Insulation Resistance Chattering Time Linearity |
20M Ω or more @ DC 25V 10 ms or less ±1.5% error or less for X axis ±1.5% error or less for Y axis |
OPTICAL | Transmittance Surface Finish | 88% to 93% per ASTM D1003 Equipment used: BYK Gardner Haze Gard Plus Anti-glare or polish |
ENVIRONMENTAL | Temperature High Temperature and Humidity Chemical Resistance |
Operating: -20℃ to 70℃ Storage: -40℃ to 85℃ 70℃ and 90% RH for 120hours Resistance to corrosives, in accordance with ASTM-D-1308-87(1993) and ASTM-D-F-15989-95 |
DURABILITY | Surface Hardness Touch Life |
Can not be scratched using any stylus with Mohs' rating of 6 or less Exceeds severe abrasion test per MIL-C-675C More than 300M touches in a single location |
WARRANTY | 5-year limited warranty |
